MAIN DIMENSIONS
Length Overall
88,6 m
Length Waterline
80,0 m.
Beam Overall
12,20 m.
Draft
3,6 m
Draft
5.00 m
DISPLACEMENT
Full Load Displacement
1700 Tons
SPEED & ENDURANCE
Max. Speed
22 Knots
Economical Speed
15 Knots
Range
3000 Nm @ 15 Knots
Endurance
4 Days
PLATFORM SYSTEMS
Main Propulsion System
2 X 5200 (kW)
Propulsion System
2 x Shafts, 2 x CP Propeller Bow Thruster (300 kW) Fin stabilizer
Generator
2 x 900 kW, 380 V AC 50 Hz
Emergency Generator
1 x 212 kW, 380 V AC 50 Hz
WEAPONS
Gun
40 mm, 40L70 Oto Melara
Machine Gun
2 x 12,7 mm
SENSORS
2D Search Radar
Electro Optical Director
Combat Management System (CMS)
Advanced software for vessels functions/operations
NAVIGATION & INTEGRATED COMMUNICATION SYSTEM
Combat Management System (CMS)
Complement
92 persons - Comfortable accommodation spaces in accordance with NATO standards
CLASSIFICATION NOTATION
Rinamil
NC+Second lne ship-patrol vessel, unrestricted navigation, SEA-KEEP, STAR-HULL, AVM-DPS(V), AUT-PORT, AUT-IAS, MON-SHAFT, HELİCOPTER LA, MARPOL I, MARPOL IV, MARPOL V, MARPOL VI
HELICOPTER OPERATIONS
Landing Platform for a general purpose helicopter (up to 10 tons) Day and night landing & takeoff capability Telescopic Hangar
REPLENISHMENT SYSTEMS
JP5 Helicopter Refueling System Replenishment at Sea (RAS) System (Starboard-Portside)
MISCELLANEOUS
External Fire Fighting System (2x1200m3/hour) Prewetting System Pollution Control and Prevention Systems 2 x RHIB Boat
Sensor and weapon configurations can be customized in accordance with the unique requirements.
